Description
Features
• High-speed I/O refreshing using the EtherCAT coupler.
• I/O refreshing synchronized with the control cycle of the controller (synchronous refreshing).
• Time-stamp inputs and outputs anywhere in the EtherCAT network can be independently controlled with
sub-microsecond accuracy.
• Detachable terminals for easy maintenance.
• Screwless Push-In Plus terminal block or MIL/Fujitsu/OTAX connector speeds up installation.
• Compact with a width of 12 mm per unit (connector type: 30 mm).
• 4, 8, 16 or 32 inputs for flexible I/O configuration (NX-ID/IA).
• 2, 4, 8, 16 or 32 outputs for flexible I/O configuration (NX-OD/OC).
• Connect to the CJ PLC using the EtherNet/IPTM bus coupler.
Specifications
I/O system NX I/O Bus
Type of module Digital I/O
Number of digital inputs 16
Digital input type PNP
Permitted voltage at input 15-28.8 V
OFF/ON delay 0.02-0.4 ms
Number of digital outputs 0
Digital output type None
Short-circuit protected outputs
Connection method 1-wire
Signal processing Free running, Standard speed, Synchronous
IO-Link master
I/O connection type Push-in
Number of I/O connectors 1
Detachable I/O connector
Suitable for safety functions
SIL according to IEC 61508 None
Communication port(s) None
Number of IOV (V+) terminals 0
Number of IOG (V-) terminals 0
Number of COM terminals 0
Degree of protection (IP) IP20
