Description
Connection type
Voltage supply 1 x male connector, M12, 4-pin, A-coded
Fieldbus, industrial network 2 x M12 female connectors, 4-pin, D-coded
Outputs
OSSD pairs 0
Safety outputs via network 4
Configuration method PC with Safety Designer (Configuration and Diagnostic Software)
Configuration and diagnostics interface USB 2.0, Mini-USB, Ethernet
Data interface
Services EtherNet/IP™ CIP Safety™
CoLa 2 (configuration and diagnostics using Safety Designer)
Data output
DHCP
SNMP
SNTP (client and server)
Fieldbus, industrial network EtherNet/IP™
Supported protocol versions Common Industrial Protocol: The CIP Networks Library Volume 1, Edition 3.20
EtherNet/IP™: The CIP Networks Library Volume 2, Edition 1.21
CIP Safety™: The CIP Networks Library Volume 5, Edition 2.13
Topology support DLR (Device Level Ring)
Display elements Graphic color display, LEDs
Features
Model Sensor including system plug
Application Indoor
Protective field range 4 m
Warning field range 40 m
Number of simultaneously monitored fields ≤ 4 1)
Number of fields 8
Number of monitoring cases 8
Scanning angle 275°
Resolution (can be configured) 30 mm, 40 mm, 50 mm, 70 mm, 150 mm, 200 mm
Angular resolution 0.39°
Response time ≥ 95 ms
Protective field supplement 65 mm
